MULTIDEPAL Medium Production

    Automatic double column machine specially designed for medium productions depalletizes containers and removes flat and / or inverted tray interlayers. The depalletizing is performed with a sliding system of the complete layer on the container unloading table, which is equipped with a multi-line outlet. The machine is also equipped with an extractor for automatic picking and handling of interlayer and pallets. The relative warehouses are available for their storage.

    • Glass bottles

      Glass bottles

    • Shaped bottles

      Shaped bottles

    • Cans


    • HDPE


    Main machine components and options:
    - Multidepal (depalletizing machine with 36sec. cycle time)
    - Container unloading bench with multi-line outfeed
    - Robot for the removal of layer pads and pallets
    - Interlayer storage warehouse
    - Empty pallet storage warehouse
    - Motorized pallet conveyors to allow continuous operation of the machine
    - Area dedicated to the undressing of pallets with appropriate stairs and walkways
    - Electrical cabinet
    - Pulpit with touch-screen control panel
    - Perimeter safety protections with mesh panels
    - Any access inside the working perimeter of the machine is allowed only through doors with micro-interlocked or if open, is controlled by photoelectric barriers

    - Storage warehouse for top cover
